| Place of Origin |
Zhejiang China (Mainland) |
| Brand Name |
HUAJING |
| Model Number |
S200 |
| Input Voltage |
85- 132VAC/176 - 264VAC by switc... |
| Output Frequency |
47-63Hz |
| Output Power |
101 - 200W |
| Output Type |
Single |
105°C Output capacitor High efficiency and low operation temperature Soft-start current can reduce the AC input impact effect With short-circuit and overload protection 100% full-load burn-in test Installed with EMI filter, minimum waveModelPerformanceS-200-5S-200-12S-200-15S-200-24DC output voltage5V12V15V24VOutput Voltage Tolerance (Note 2)±2%±1%±1%±1%Rated output current40A16.5A13.3A8.5AOutput Current Range0 -40A0 -16.5A0 -13.3A0 -8.5ARipple and noise (Note 3)100mVp-p120mVp-p120mVp-p120mVp-pInto the line of stability (Note 4)±0.5%±0.5%±0.5%±0.5%Load stability (Note 5)±1%±0.5%±0.5%±0.5%DC output power200W200W200W200WEfficiency75%79.5%80%81.5%DC voltage adjustable range4.75-5.5V10.8-13.2V13.5-16.5V21.6-26.4VInput Voltage Range85 132VAC/176 264VAC by switch 47 63Hz;Input Current4.2A /115V, 2.2A /230VInrush CurrentCurrent 30A/115V 60A/230V cold startLeakage<0.5mA/240VACOverload105% -150% Type:pulsing hiccup shutdown reset: auto recovery
